ASTM A240 316L Steel Plate

    Type: Plate, Sheet, Strip, Coil
    Length: 0-12m
    Width: 0-2500mm
    Thickness: 0.3-1200mm
    Process: Hot/Cold Rolled
    Surface: 1,2D,2B BA,3,4,6,7
+86 18865211873
ganmaimai@qq.com

ASTM A240 316L Steel Plate, Largest Stockholder of Stainless Steel 316 Sheets and Plates in China, Ready Stock of X2CrNiMo18-14-3 Stainless Steel Plates, Stainless Steel 316 Perforated Sheets, Competitive Price of Stainless Steel 316L Sheet.

ASTM A240 316L Steel Plate has a high level of strength and thermal stability applicable to hot working applications. Stainless Steel UNS S31600 Plate is the molybdenum austenitic stainless steel that offers overall corrosion-resistant and weldability, formability. 1.4401 Sheet provides resistance to crevice corrosion, chloride corrosion, pitting, etc.



SS 316 Sheets and Plates have high carbon content, suitable for annealed conditions and high-temperature applications. SS 316L is the low carbon version of Stainless Steel, which is hard enough to use in high-stress situations. ASME SA 240 316L Plate has a higher amount of chromium-nickel to provide resistance to pitting, chloride solutions, crevice corrosion, and oxidizing agent. It is suitable to prefer heavy gauge welded components. SS 316L Sheets & Plates is non-magnetic, has the ability to survive in the corrosive environment for applications.



As ASTM A240 316L Steel Plate Manufacturer, HT PIPE has a well-equipped production plant with modern upgraded technology. We have reliable vendors in contact to bring premium quality grade raw materials for manufacturing standard quality 316L Sheets and Plates.


Chemical Composition of Stainless Steel 316 / 316L Sheets & Plates

Grade

C

Mn

Si

P

S

Cr

Mo

Ni

N

SS 316L

0.035 max

2 max

1.00 max

0.045 max

0.030 max

16.00 – 18.00

2.00 – 3.00

10.00 – 14.00

68.89 min



Mechanical Properties of Stainless Steel A240 TP316 / 316L Sheets & Plates


Grade

Density

Melting Point

Tensile Strength

Yield Strength (0.2%Offset)

Elongation

SS 316L

8.0 g/cm3

1399 °C (2550 °F)

Psi – 75000 , MPa – 515

Psi – 30000 , MPa – 205

35 %
