ASTM A312 UNS S31635 AISI 316Ti Stainless Steel 316Ti Welded Pipes

+86 18865211873

ganmaimai@qq.com

ASTM A312 UNS S31635 AISI 316Ti Stainless Steel 316Ti Welded Pipes, 316Ti Stainless Steel Pipes and Tubes Manufacturer, ASME SA 312 TP316Ti Pipe, SS 316ti ERW Pipe, UNS S31635 Pipes, 316Ti Stainless Steel Welded Pipes and Tubes, 316Ti Stainless Steel Tubing.

ASTM A312 UNS S31635 AISI 316Ti Stainless Steel 316Ti Welded Pipes:

ASTM A312 UNS S31635 AISI 316Ti Stainless Steel 316Ti Welded Pipe is a titanium stabilised version of 316 molybdenum-bearing austenitic stainless steel. The 316Ti Stainless Steel Pipes and Tubes are more resistant to general corrosion and pitting/crevice corrosion than the conventional chromium-nickel austenitic stainless steels such as 304.

ASTM A312 UNS S31635 AISI 316Ti Stainless Steel 316Ti Welded Pipes also offer higher creep, stress-rupture and tensile strength at elevated temperature. High carbon Alloy 316 stainless steel can be susceptible to sensitisation, the formation of grain boundary chromium carbides at temperatures between approximately 900 and 1500°F (425 to 815°C) which can result in intergranular corrosion. Resistance to sensitisation is achieved in ASME SA 312 TP316Ti Pipe with titanium additions to stabilise the structure against chromium carbide precipitation, which is the source of sensitisation.

This ASTM A312 UNS S31635 AISI 316Ti Stainless Steel 316Ti Welded Pipes stabilisation is achieved by an intermediate temperature heat treatment, during which the titanium reacts with carbon to form titanium carbides.

1. SS 316Ti Pipe Stock Size Range and Specifications

Grade	Stainless Steel 316Ti / SS TP 316Ti / DIN 1.4571 Pipes / UNS S31635 Pipes
Standard	ASTM / ASME SA213 / A249 / A269 / A312 / A358 CL. I to V ASTM A789 / A790
Steel EFW 316Ti Pipes	6" NB - 100" NB
Form	Round, Square, Rectangular, Hydraulic Etc
Schedule	SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Length	Single Random, Double Random & Cut Length. (Custom Sizes Available as per customers requirement)
Type	Seamless / ERW / Welded / Fabricated / EFW
End	Plain End, Beveled End, Treaded

2. About Stainless Steel 316Ti Pipe Tube

Standard	SS 316TI
Werkstoff Nr.	1.4571
UNS	S31635
JIS	SUS 316Ti
AFNOR	Z6CNDT17-12
BS	320S31
GOST	08Ch17N13M2T
EN	X6CrNiMoTi17-12-2

316Ti Stainless Steel Pipes Chemical Composition

Grade		C	Mn	Si	P	S	Cr	Mo	Ni	N
316Ti	min.	–	–	–	–	–	16.0	2.00	10.0	–
316Ti	max.	0.08	2.0	0.75	0.045	0.030	18.0	3.00	14.0	–

Stainless Steel 316Ti Pipe Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
				Rockwell B (HR B) max	Brinell (HB) max
316Ti	515	205	35	75	205

Stainless Steel 316Ti Pipes Physical Properties

Grade	Density (kg/m3)	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion (m/m/0C)			Thermal Conductivity (W/m.K)		Specific Heat 0-1000C (J/kg.K)	Electrical Resistivity (n.m)
			0-1000C	0-3150C	0-5380C	at 1000C	at 5000C
316Ti	8000	193	17.2	17.8	18.4	16.2	21.5	500	720

3. Types of Stainless Steel Welded Pipes

Stainless Steel 316Ti Welded Pipe	SS 316Ti Welded Pipe 316Ti SS Welded Pipe SS 316Ti ERW Pipe SS 316Ti EFW Pipe Stainless Steel 316Ti ERW Pipe Stainless Steel 316Ti EFW Pipe 316Ti Stainless Steel Welded Pipe UNS S30400 Welded Pipe WERKSTOFF NR. 1.4571 Welded Pipe ASTM A312 TP 316Ti Stainless Steel Welded Pipes
Stainless Steel 316Ti Round Pipe	SS 316Ti Round Pipe 316Ti SS Round Pipe 316Ti Stainless Steel Round Pipe GOST 08Ch17N13M2T Round Pipe UNS S31635 Round Pipe SS UNS S31635 Round Pipe ASTM A312 TP 316Ti Stainless Steel Round Pipes
Stainless Steel 316Ti Square Pipe	SS 316Ti Square Pipe 316Ti SS Square Pipe 316Ti Stainless Steel Square Pipe UNS S31635 Square Pipe WERKSTOFF NR. 1.4571 Square Pipe ASTM A312 TP 316Ti Stainless Steel Square Pipes

4. ASME SA358 SS 316Ti Pipes Popular Searches

ERW Stainless Steel 316Ti pipe, Fabricated Stainless Steel 316Ti Pipe , CDW Stainless Steel 316Ti Pipe, Stainless Steel 316Ti Cold Drawn Seamless Pipe, marine stainless steel 316Ti Piping, 10mm stainless steel 316Ti Pipe, 40mm stainless steel 316Ti Pipes, 12mm stainless steel 316Ti Pipe, stainless steel 316Ti pipe price, 4 inch 316Ti stainless steel pipe price, stainless steel 316Ti pipe price per foot, SS 316Ti pipe price, SS 316Ti pipe, SS 316Ti pipes, SS 316Ti pipes manufacturers, 3 inch stainless steel 316Ti pipe, 8 inch stainless steel 316Ti pipe, 1 inch 316Ti stainless steel pipe, 316Ti stainless steel pipe 2 inch, 316Ti stainless steel 2 inch pipe, 2.5 inch stainless steel 316Ti pipe, 12 inch stainless steel 316Ti pipe, stainless steel 316Ti pipe manufacturers, 316Ti stainless steel Pipe manufacturers, 316Ti stainless pipe manufacturers, 316Ti stainless steel pipe, SS 316Ti pipe, 316Ti SS pipe, 316Ti stainless steel welded pipe, 316Ti stainless steel welded pipes, large diameter 316Ti stainless steel pipe, large 316Ti stainless steel pipe, thick wall 316Ti stainless steel pipe, thin wall 316Ti stainless steel pipe, 316Ti stainless steel piping wall thickness.
