Nickel Alloy Pipe And Tube Hastelloy C276 C22 B2 With Good Price And High Purity

+86 18865211873

ganmaimai@qq.com

Hastelloy Alloy C276 Pipes & Tubes, Latest Price of Hastelloy Alloy C22 Pipes & Tubes, Hastelloy Alloy C276 Pipes & Tubes Price, UNS N06022 Hastelloy Pipes & Tubes, UNS N10276 Hastelloy Alloy Pipes & Tubes

Hastelloy is a high-performance nickel-based alloy that is known for its excellent corrosion resistance, strength, and durability. Hastelloy is commonly used in applications where harsh conditions exist, including high-temperature, high-pressure, and highly corrosive environments. Hastelloy pipe is a popular choice for many industries, including chemical processing, oil and gas, power generation, and aerospace. In this article, we will discuss the material grades, standards, process, chemical composition, properties, application, and more about Hastelloy pipes.

Hastelloy Pipes are manufactured in accordance with various international standards such as ASTM, ASME, and API. These standards outline the specific requirements for the manufacture, testing, and inspection of the pipes to ensure their quality and durability.

Some of the common standards for Hastelloy pipes are:

• ASTM B622/B619/B626/B775/B829

• ASME SB622/SB619/SB626/SB775/SB829

C276/C22/B2 Hastelloy Pipes & Tubes Specification :

Specifications	ASTM B622 ASME SB622 / ASTM B619 ASME SB619
Dimensions	ASTM, ASME, and API
Size	1/2″NB TO 12 "NB IN
Specialized in	Large Diameter Size
Schedule	SCH5, SCH10, SCH20, SCH30, SCH40, STD, SCH80, SCH 80S, SCH60, SCH80, SCH120, SCH140, SCH160, SCH XXS, SCH XS
Type	Seamless / ERW / Welded / Fabricated
Form	Seamless Pipes, ERW Pipe, EFW, Pipe, Seamless Tube, ERW Tube, Square Pipe.
Length	Single Random, Double Random & Required Length.
End	Plain End, Beveled End, Treaded

Hastelloy C276/C22/B2 Pipes & Tubes Chemical Composition

Grade	Ni	C	Mo	Mn	Si	Fe	P	S	Co	Cr
Hastelloy C276	Balance	0.01 max	15 – 17	1.0 max	0.08 max	4 – 7	0.04 max	0.03 max	2.5 max	14.5 – 16.5
Hastelloy C22	Balance	0.010 max	12.5 – 14.5	0.50 max	0.08 max	2 – 6	0.02 max	0.02 max	2.5 max	20 – 22.5
Hastelloy B2	Balance	0.02 max	26.0-30.0	1.0 max	0.10 max	2.0 max	0.040 max	0.030 max	1.0 max	1.0 max

Mechanical Properties of C276/C22/B2 Hastelloy Pipes & Tubes

Grade	Density	Melting Point	Yield Strength (0.2%Offset)	Tensile Strength	Elongation
Hastelloy C276	8.89 g/cm3	1370 °C (2500 °F)	Psi – 52,000, MPa – 355	Psi – 1,15,000, MPa – 790	40 %
Hastelloy C22	8.69 g/cm3	1399 °C (2550 °F)	Psi – 45000, MPa – 310	Psi – 1,00,000, MPa – 690	45 %
Hastelloy B2	9.2 g/cm3	1370 °C (2500 °F)	Psi – 51,000, MPa – 350	Psi -1,10,000, MPa -760	40 %

Equivalent Grades of Hastelloy C276/C22/B2 Pipes & Tubes

STANDARD	UNS	WERKSTOFF NR.	AFNOR	EN	JIS	OR	GOST
Hastelloy C276	N10276	2.4819	–	NiMo16Cr15W	NW 0276	ЭП760	ХН65МВУ
Hastelloy C22	N06022	2.4602	–	NiCr21Mo14W	NW 6022	–	–
Hastelloy B2	N10276	2.4617	–	–	–	–	–
