N02200 Nickel 200 Steel Plate Sheet Coil, Nickel 200 Hot Rolled Plates, ASME SB 730 Nickel UNS N02200 Plates, ASME SB 161 Nickel 200 Hot Rolled Plates, Grade 200 Nickel Sheets, ASTM B725 Nickel UNS N02200 Sheets, Nickel 200 Plates Provider.

Grade 200 Nickel Alloy Plate is an unalloyed form of wrought nickel or otherwise known as a commercially pure wrought Nickel . One of the benefits of using Nickel 200 Steel Plate Sheet is that the metal is considered to offer good mechanical properties over a broad temperature range.

Additionally, the Nickel 200 Alloy Hot Rolled Plate demonstrates excellent resistance to many corrosives, particular in those conditions where the alloy has been exposed to hydroxides. Under reducing conditions, the Nickel UNS N02200 Flat Plate tends to be most useful and has the ability to offer good resistance to corrosion in acids and alkalis. Hence, the ASME SB162 Nickel 200 Strip has been used in the manufacture and handling of sodium hydroxide, predominantly at temperature above 300C. In fact, the Nickel 200 Steel Plate Sheet has outstanding resistance to caustic alkalis up to and including its resistance to them even the molten state.

UNS Number N02200
Other common names: Nickel 200

In What Form Is Nickel 200 Available?
• Sheet
• Plate
• Bar
• Pipe & Tube (welded & seamless)
• Wire

Chemical Analysis

Weight % (all values are maximum unless a range is otherwise indicated)

Physical Properties

Density

0.321 lbs/in3
8.89 g/cm3

Specific Heat

0.109 BTU/lb-°F (32—212°F)
456 J/kg-°K (0—100°C)

Modulus of Elasticity 78°F (26°C)

29.7 x 103 ksi
205 GPa (20°C)

Thermal Conductivity 212°F (100°C)

463 BTU-in/ft2-h-°F
66.5 W/m-°C

Melting Range

2615 – 2635°F
1435 – 1446°C

Electrical Resistivity

58 Ohm-circ mil/ft at 70°F
0.096 µΩ/m at 20°C

Mean Linear Expansion

Mechanical Properties

Nickel 200, Typical Values at 70°F (21°C), Plate—Hot Rolled, Annealed
